TGX HAMMER
TGX HAMMER
TGX HAMMER
TGX Hammer does not need foot valve of bit. It eliminates operation problem associated with the foot valve.
TGX hammers perform well with higher piston frequency for softer formation.
TGX HAMMER Specification
| model | TGX50 | TGX60 | TDU60C | TGX80 | ||||
|---|---|---|---|---|---|---|---|---|
| Connection | API 3 1/2" Reg. Pin | API 3 1/2" Reg. Pin | API 3 1/2" Reg. Pin | API 4 1/2" Reg. Pin | ||||
| Bit Shank | M50 | DHD360 | QL60 | SD8 | ||||
| Reversible casing | NO | NO | NO | NO | ||||
| General Specifications | Metric | Imperial | Metric | Imperial | Metric | Imperial | Metric | Imperial |
| Recommended bit diameter | 130 - 152 | 5 1/8 - 6 | 158 - 194 | 6 2/9 - 7 2/3 | 152 - 194 | 6 - 7 2/3 | 195 - 270 | 7 2/3 - 10 5/8 |
| Outside Diameter | 118 | 4.65 | 144 | 5.67 | 142 | 5.59 | 182 | 7.17 |
| Length w/o connection & bit | 1031.0 | 40.6 | 1089.0 | 42.9 | 1088.0 | 42.8 | 1182.0 | 46.5 |
| Weight w/o bit | 61.0 | 134.6 | 100.0 | 220.4 | 97.0 | 214.0 | 171.7 | 378.6 |
| Backhead across flats (mm) | 40 X 100 AF | 40 X 100 AF | 50 X 10 AF | 60 X 148 AF | ||||
| Air Consumption | ||||||||
| 10.3 BAR / 150 PSI (m³/min & cfm) | 8.2 | 290 | 11.2 | 395 | 11.2 | 395 | 14.4 | 510 |
| 13.8 BAR / 200 PSI (m³/min & cfm) | 11.2 | 393 | 14.7 | 514 | 14.7 | 514 | 19.7 | 695 |
| 17.2 BAR / 250 PSI (m³/min & cfm) | 13.9 | 490 | 17.6 | 620 | 17.6 | 620 | 25.0 | 885 |
| 24.1 BAR / 350 PSI (m³/min & cfm) | 20.4 | 720 | 26.0 | 920 | 26.0 | 920 | 36.0 | 1259 |
| Available Options | ||||||||
| Bit Shank | QL50 | SD6 / M60 / QL60 | SD6 / M60 / DHD360 | DHD380 / QL80 / M80 | ||||
| Bit retainer system | ||||||||
| Heavy Duty Design | YES (152mm / 6") | YES (152mm / 6") | ||||||
